| Output Power | 20 W |
| Brand | MAX |
| Voltage | 220 |
| Phase | SINGLE |
| Working Life | 1 LAC HOURS |
| Application | METAL |
| Model Name/Number | 30X, 20X, 50X / 20P, 30P / 20W, 30W, 50W |
Minimum order quantity:Â 1 Piece
| Model | RFL-P20QE | RFL-P20QS | RFL-P30QS | RFL-P30Q | RFL-P50QB | RFL-P100Q |
| Average Output Power | 20 | 20 | 30 | 30 | 50 | 100 |
| Central Wavelength(nm) | 20-60 | 20-60 | 30-60 | 30-60 | 50-100 | 20-200 |
| Output Power Stability | <3% | <5% | ||||
| Output Beam Dia(mm) | 7±1 | 6.5±1 | ||||
| M² | <1.5 | <1.6 | <1.8 | |||
| Pulse Width(ns) | 110-140 | 110-140 | 130-150 | 110-130 | 120-150 | 50-110 |
| Max.Single Pulse Energy(mJ) | 0.67 | 0.75 | 1 | |||
| Delivery Cable Length(m) | 2(Customizable) | |||||
| Power Supply(VDC) | 24 | |||||
| Power Range(%) | 10-100% | |||||
| Power Consumption(W) | 170 | 170 | 200 | 240 | 340 | 450 |
| Cooling | Air | |||||
| Operating Temperature | 0-40 | |||||
| Warranty | Two years | |||||
