Sk-2000
- Four-color printing, 1.52m wide format output;
Different kinds of ink can be choosed, made the picture more gorgeous and lifelike;
- Printing resolution can reach to 1440dpi, even the word is small as 0.5mm;
- Three different sizes of dots, achieving the complement of point technology, eliminating the granular sensation of the images, even under high speed or low resolution, high quality images can be printed.
- Multi-row pinch rollers ensure the machine can print with an accurate size of feeding media.
Technical Parameters and Specifications:
| Printhead |
Micro Piezo technology(180 nozzles x 8 lines)*1 head |
Print Width |
1520mm(60”) |
Resolution |
540, 720, 1440dpi |
Print Mode |
540x720dpi, 720x720dpi, 720x1440dpi, 1440x1440dpi |
Ink Type |
Solvent ink-SS21 |
Eco Solvent ink-ES3 |
Water-based ink |
Media |
Flex Banner, Adhesive Vinyl, PVC, Mesh, One Way Vision, Eco Solvent Inkjet Paper, etc. |
Heating System |
Front, middle, back three sections |
Media Take-up device |
Equipped |
Operation Environments |
Temperature: 20℃-35℃(68℉-95℉) |
Humidity: 35%-65%Rh |
Application Standards |
VCCI Class A, FCC Class A, UL 60950, CE Marking, CB report |
Interface |
USB2.0 |
Power Supply |
AC100V-120V±10%, AC220V-240V±10%, 50/60±1Hz |
Electricity Consumption |
Below 1440VA |
Inkjet Meida |
Width: 1620mm(63.9”) |
Weight: below 25kg(55.1lbs) |
Media Surface: Face out |
Inner Diameter: 50.8mm(2in.) or 76.2mm(3in.) |
Certificate |
UL, FCC, CSA, TUV, CE Mark, ISO9001:2000 |
Machine Weight |
160kg(353lbs) |
Machine Size |
L*W*H: 2.54*0.74*1.42m(99.9”*29.1”*56.1”) |
Standard Print Speeds 1400 dpi ’ Output in square feet per hour(square meters per hour)
| Draft Mode |
188 sfph (17.5 smph) |
Production Mode |
160 sfph (14.9 smph) |
Photo mode |
128 sfph (11.9smph) |
Hyperfine Mode |
80 sfph (7.4smph) |
|
|
|
|
|
|
 |
|
 |
|
|
